Alpro 5102 Size 2 Transom Closer with Hold Open

Compare

These Alpro T2 Transom Closers have a fixed strength size 2 and can be used on a single or double action door. These closers can be used on doors with a maximum weight of 100kg ,a maximum width of 950mm, and are tested to BS EN1154.

£105.93

These Alpro T2 Transom Closers have a fixed strength size 2 and can be used on a single or double action door.
These closers can be used on doors with a maximum weight of 100kg ,a maximum width of 950mm, and are tested to BS EN1154.
Features include hold open, back check, adjustable closing speed and adjustable latch action – See FAQs for more information on how these functions work.
510290T1 – Supplied with Side Load Arm, Bottom Pivot & Fixings.
510290T2 – Supplied with End Load Arm, Bottom Pivot & Fixings.

  • Fitting: Concealed – Fitted into the transom above the door.
  • Tested to BS EN1154.
  • Height: 37mm
  • Width: 90mm
  • Length: 293mm
  • Spindle: Standard Spindle Length – 12mm – Also available in 17,22 and 28mm as a special order
  • Maximum Door Weight: 100kg
  • Maximum Door Width – 950mm
  • Strength: Fixed Size 2
  • Adjustable Closing Speed: Yes.
  • Adjustable Latch Action: Yes.
  • Delayed Action: No.
  • Backcheck: Yes.
  • Hold Open – Yes 90 Degree
  • Non Handed.

Product FAQs

Adjustable closing speed allows for the adjustment of the speed with which the door is closed.

What is delayed Action?

Delayed action allows the closer to close the door more slowly at the top of its cycle.

What is hold open?

Hold open means the door can be held in the open position.

How do I know what strength door closer I need?

The strength required is selected depending on the doors width and weight.

What is adjustable latch action?

Adjustable latch action allows the speed over the final 7-10 degrees to be adjusted to overcome latches and seals.

SKU: N/A Categories: , Brand:
Side Or End Load

End, Side
